Lifting Switch for Grane

Basic Info.

Model NO.	NM-8166
Breaking Form	Duplex Type
Brand	Nanma
Certification	CE, CCC
Material	Metal
Type	Elevator Parts
IP	65
Weight	130g-190g
Transport Package	10PCS in One Box
Specification	CE
Trademark	Chnanma or as customer request
Origin	Yueqing, Zhejiang China (Mainland)
HS Code	8543909000
Production Capacity	500, 000 Per/Month

Product Description

1.Switch Feature: 1)Roller Arm Type limit switch N/O and N/C, brass contact, Silver tip.2)Double circuit type of limit switch with roller lever arm.3)Highly rigid construction, consists of intensive plastic and aluminum cast.4)Small volume, water-proof and oil-proof construction.5)Built-in basic switch with double spring mechanism, longer mechanical life.6)Smooth operation with greater OT.7)Easy-to-wire circuit opening design.8)Wide varity of actuators, easily use.2.Specifications

Rated voltage	Non-inductive load				Inductive load
	Resistive load		lamp load		Inductive load		Moto load
	N.C	N.O	N.C	N.O	N.C	N.O	N.C	N.O
125 VAC	5	5	1.5	0.7	3	3	2	1
250 VAC	5	5	1	0.5	3	3	1.5	0.8
8 VDC	5	5	3	3	5	4	3	3
14 VDC	5	5	3	3	4	4	3	3
30 VDC	5	5	3	3	4	4	3	3
125 VDC	0.4	0.2	-	-	-	-	-	-
250 VDC	0.4	0.24	-	-	-	-	-	-

3.Characteristics

Operating speed	5mm to 5cm/s
Operating frequency	120operation/min
contact resistance	25mΩ max (initial)
Insulation resistance	100mΩ min (at 500VDC)
Dielectric strength	11,000VAC,50/60Hz for 1 minute between non-continuous terminals
	1,500VAC,50/60Hz for 1 minute between current carrying and non-current carrying parts and between each terminals and ground
Vibration	10 to 55Hz,1.55mm double amplitude
Shock	Approx,300m/s²(approx,30G's
Ambient temperature	Operating:-5 to +65ºC
Humidity	95% RH max.
Service	Mechanically 10,000,000 operations min.
	electrically 500,000 operations min.
Weight	Approx. 130 to 190g
Degree of protection	IEC:IP65

4.Operating Characteristics

Model	NM-8166
OF Max	150g
RF
PT Max	30mm
OT
MD
OP

5.Why choose Us?1) We can provide you with different types of micro switches for your selection.2) We can offer good quality electric life 500, 000-1, 000, 000times.3) Various operating force, height and color for one switch for your choice.4) Safety, on-time delivery, excellent quality with competitive price.5) ODM&OEM professional design.6CUSTOMER'S QUESTIONSQ1:How about the delivery time?Answer:It's depends on the quantity, for example, 10000PCS need to OEM,delivery time is 3-7 days.Q2:What quality you can offer to us?Answer:We now can do 1/2 years warranty, during the warranty time we can exchange all defective products from customers for free.Q3:Can you give me samples to test?Answer:YesQ4:What's your MOQ?Answer:MOQ 2500PCS, mixed order acceptable, welcome trial order.Q5:What's the delivery term?Answer:Both EXW and FOB Ningbo are acceptable.Q6:What's the payment term?We could start our discussion about payment term from second order on.Q7:What's the shipment way?Answer:Express:DHL, UPS, FedEx, TNT and SF express.Forwarder:Air shipment or sea shipment.6.More information of our products, please do feel free to contact us.Reply will be available within 24 hours. Thanks!
